The fully automatic ultrasonic cross cutting machine for eyeglass fabric adopts an ultrasonic system to cut the eyeglass fabric. Multiple cutting methods such as single blade straight cutting, embossed straight cutting, and pattern edge cutting can be selected for cutting. After slitting, the edges are soft and the silk edges are sturdy, without shedding fabric scraps, discoloration, blackening, or burrs. It is an ideal equipment for making eyeglass cloth. This machine reduces raw material waste by 10%, and it has multiple options such as strip to circle/strip to cross cut, with adjustable dimensions (Non standard customization can be made according to customer requirements)
Equipment features:
1. Automatic feeding does not require the use of a drum for rewinding, and the entire roll of material can be shelved for operation, replacing traditional slitting processes and achieving automated operation of the entire machine, resulting in increased production efficiency;
2. The cross cutting part is guided by double linear sliding rails, and precision screw transmission ensures stable operation of the machine. The fabric is not warped during cross cutting, and the cutting width and length can be adjusted and arranged arbitrarily, making operation convenient;
3. High cutting length accuracy, automatic feeding, computer counting, fast speed, and adjustable strip width and length;
4. Adopting an ultrasonic system, the fabric cutting edges do not change color, have no rough edges, do not turn yellow, do not shed silk, do not shed chips, and automatically seal the edges;
5. The material pulling and wrapping roller is made of rubber, and the surface is processed by a precision cylindrical grinder. The spreading material is not deformed, and the feeding and discharging before and after the machine are uniform and flat
Model----------------------------------------HD-1108
Machine specifications----------------------3000mm*2500mm*1800mm
Efficiency-------------------------------------50-70 pcs/min
Voltage---------------------------------------380V
Air pressure----------------------------------3-7kg/cm ²
Power----------------------------------------7000W
Established industry university research and development cooperation with well-known domestic universities such as the Chinese Academy of Sciences, the University of Hong Kong, Soochow University, and Zhengzhou Institute of Technology
The factory has introduced modern management systems such as OA, CRM, and ERP for digital informatization, scientific management, efficient and high-quality production, and reduced labor and time
Famous domestic and foreign brand components, lean production management, full inspection and certification of quality, strictly following the ISO 9001 production quality management system
Professional engineer service support, industry technical elites quickly solve your needs, providing customers with a professional, fast, and superior service experience.
